E51 Rebuild Kit

Where can I find a rebuild kit for the E51?
oasis is offline
Sponsored Links
Advertisement

post #2 of 19 (permalink) Old May 1st, 2011, 01:20
Registered User

filonin_2's Avatar

Join Date: Nov 2005
Location: North Highlands, CA
Age: 33
Posts: 8,745
OldTrader Rating: (11)
You can't. You can however use e-153 internals. I had a transmission shop rebuild my e-51 using the gears from an e-153. Now I have double cone synchros and the parts for an e-153 are much cheaper. I used a 93+ trans and the LSD wouldn't fit in the e-51 case. Rumor has it the pre 93 one will.
filonin_2 is offline
post #3 of 19 (permalink) Old May 1st, 2011, 03:58 Thread Starter
Registered User

Join Date: Mar 2004
Posts: 733
OldTrader Rating: (8)
So you can still get new gears, parts etc. for the e153? Any reason you used a 93+ trans vs ealier e153? Do you know if the e153 syncros will simply swap over to the e51 gears?
oasis is offline
Sponsored Links
Advertisement

post #4 of 19 (permalink) Old May 1st, 2011, 12:28
Registered User

filonin_2's Avatar

Join Date: Nov 2005
Location: North Highlands, CA
Age: 33
Posts: 8,745
OldTrader Rating: (11)
All I know is that two years ago, the trans shop quoted me $900 in parts alone to fix the e-51. I was able to score a 93+ e-153 trans with a hole in the case for $350. It still needed a couple of synchros replaced but it was way WAY cheaper. The trans shop was sourcing the parts so I don't know where they were getting them. I chose the 93+ because I had read that the gears would fit, which turned out to be true. I still don't know about the pre 93 LSD fitting but I want to try it one day. I don't know if the 93+ synchros fit on the e-51 gears, but I wouldn't think they would.
filonin_2 is offline
post #5 of 19 (permalink) Old May 1st, 2011, 18:05 Thread Starter
Registered User

Join Date: Mar 2004
Posts: 733
OldTrader Rating: (8)
What's the e153 gearing like? Did the sc axles fit without any issues or did you have to use the e153 stub shafts?
oasis is offline
post #6 of 19 (permalink) Old May 1st, 2011, 20:35
Registered User

MRguyandhis2Turbo's Avatar

Join Date: Oct 2007
Location: Livin Rent free in UR Head, NV
Age: 32
Posts: 3,565
OldTrader Rating: (14)
Garage
The e51 and e 153 (lsd and non lsd) all have the exact same gearing. If your gonna take it apart I would try and grab the 93+ tranny the gears will drop right in. But since you would have the gears out try and locate a 5speed v6 camry final gear. Instead of crusing @ 3500ish rpms u should cruis around 2500 irrc. V6 5speed camery is also the same gearing except the fiinal drive. That's exactly what imma due when I have to replace the gears.
MRguyandhis2Turbo is offline
post #7 of 19 (permalink) Old May 1st, 2011, 20:36
Registered User

MRguyandhis2Turbo's Avatar

Join Date: Oct 2007
Location: Livin Rent free in UR Head, NV
Age: 32
Posts: 3,565
OldTrader Rating: (14)
Garage
Quote:
Originally Posted by oasis
What's the e153 gearing like? Did the sc axles fit without any issues or did you have to use the e153 stub shafts?
He didn't put the whole e153 (mk2 turbo) tranny into his mk1. He used the e51 (the mk1 sc tranny) and just swapped over internals.
MRguyandhis2Turbo is offline
post #8 of 19 (permalink) Old May 2nd, 2011, 00:28 Thread Starter
Registered User

Join Date: Mar 2004
Posts: 733
OldTrader Rating: (8)
I understand that we're talking internals here, I'm just unclear about whether he used the e51 diff, or an early e153 diff, or later e153 non-lsd...

Quote:
Originally Posted by MRguyandhis2Turbo
He didn't put the whole e153 (mk2 turbo) tranny into his mk1. He used the e51 (the mk1 sc tranny) and just swapped over internals.
oasis is offline
post #9 of 19 (permalink) Old May 2nd, 2011, 00:29 Thread Starter
Registered User

Join Date: Mar 2004
Posts: 733
OldTrader Rating: (8)
Thanks for the info, I'm going to look into the camry final drive.

Quote:
Originally Posted by MRguyandhis2Turbo
The e51 and e 153 (lsd and non lsd) all have the exact same gearing. If your gonna take it apart I would try and grab the 93+ tranny the gears will drop right in. But since you would have the gears out try and locate a 5speed v6 camry final gear. Instead of crusing @ 3500ish rpms u should cruis around 2500 irrc. V6 5speed camery is also the same gearing except the fiinal drive. That's exactly what imma due when I have to replace the gears.
oasis is offline
post #10 of 19 (permalink) Old May 2nd, 2011, 08:39
Registered User

Join Date: May 2005
Location: Quincy, MA
Age: 33
Posts: 4,600
OldTrader Rating: (15)
slightly off-topic, but will the E51 bellhousing swap on to the E153? I assume yes, but...
Turbowned is offline
post #11 of 19 (permalink) Old May 2nd, 2011, 14:26
Registered User

MRguyandhis2Turbo's Avatar

Join Date: Oct 2007
Location: Livin Rent free in UR Head, NV
Age: 32
Posts: 3,565
OldTrader Rating: (14)
Garage
Quote:
Originally Posted by Turbowned
slightly off-topic, but will the E51 bellhousing swap on to the E153? I assume yes, but...
yes they are
MRguyandhis2Turbo is offline
post #12 of 19 (permalink) Old May 2nd, 2011, 14:29
Registered User

MRguyandhis2Turbo's Avatar

Join Date: Oct 2007
Location: Livin Rent free in UR Head, NV
Age: 32
Posts: 3,565
OldTrader Rating: (14)
Garage
Quote:
Originally Posted by oasis
I understand that we're talking internals here, I'm just unclear about whether he used the e51 diff, or an early e153 diff, or later e153 non-lsd...
Quote:
Originally Posted by filonin_2
I used a 93+ trans and the LSD wouldn't fit in the e-51 case. Rumor has it the pre 93 one will.
that would indicate he used the e51 diff
MRguyandhis2Turbo is offline
post #13 of 19 (permalink) Old May 2nd, 2011, 19:57 Thread Starter
Registered User

Join Date: Mar 2004
Posts: 733
OldTrader Rating: (8)
Ahhh. I guess I should of read that a third time over - thanks again!
oasis is offline
post #14 of 19 (permalink) Old May 2nd, 2011, 20:39
Registered User

MRguyandhis2Turbo's Avatar

Join Date: Oct 2007
Location: Livin Rent free in UR Head, NV
Age: 32
Posts: 3,565
OldTrader Rating: (14)
Garage
lol no problem
MRguyandhis2Turbo is offline
post #15 of 19 (permalink) Old May 3rd, 2011, 10:49
Registered User

Join Date: Feb 2008
Location: Colorado Springs, CO
Age: 36
Posts: 3,265
OldTrader Rating: (6)
So E51 diff with E153 ring gear on it?
supercharged111 is offline
post #16 of 19 (permalink) Old May 4th, 2011, 14:23
Registered User

filonin_2's Avatar

Join Date: Nov 2005
Location: North Highlands, CA
Age: 33
Posts: 8,745
OldTrader Rating: (11)
Quote:
Originally Posted by Turbowned
slightly off-topic, but will the E51 bellhousing swap on to the E153? I assume yes, but...
This is actually what I wanted to do, but because the 93+ LSD is a different size, and hence the area of the case for the LSD, this can't work. It *MAY* be possible using a pre 93 e-153. About the ring gear, I don't know which one was used in my trans.

Quote:
Originally Posted by MRguyandhis2Turbo
that would indicate he used the e51 diff
Correct.

Last edited by filonin_2; May 4th, 2011 at 14:25.
filonin_2 is offline
post #17 of 19 (permalink) Old May 16th, 2019, 21:29
Registered User

Join Date: Jun 2008
Location: Washougal, WA
Posts: 103
OldTrader Rating: (0)
So to bring back a very old thread, I need to rebuild my E51 trans on my 89 SC. So will the E153 synchros fit on the E51 gears or do I need to change the gears out from an E153? I want to use synchros from a 94/95 MR2 since I heard that they are much improved over earlier versions.

Does the use of the Camry FD hurt the acceleration a lot since it lowers rpm at higher speeds so much?

Does anyone know of any good transmission shops in Oregon/Washington that they know do good work?

Last edited by JBKBS5; May 18th, 2019 at 22:25.
JBKBS5 is offline
post #18 of 19 (permalink) Old May 19th, 2019, 00:14
Registered User

Join Date: Jun 2008
Location: Washougal, WA
Posts: 103
OldTrader Rating: (0)
So I'm guessing that rebuilding my E51 transmission from my 89 SC is best done using gears and synchros from a 93+ E153 from a 2nd Gen MR2. Is there a place that sells the gears, synchros, seals and anything else that would be needed? Is it better to look for a used E153 and gut it using the gears and other parts? Hard to tell what condition it would be in. I would like to find a rebuild kit with all new parts. I'm hoping that someone can help me. It seems amazing to me that it could be so hard to find these parts as there are still plenty of MR2's on the road. Help me keep my baby on the road and shifting smoothly!!!
JBKBS5 is offline
post #19 of 19 (permalink) Old May 19th, 2019, 01:44
Registered User

Join Date: Feb 2016
Location: Maui, HI
Posts: 1,135
OldTrader Rating: (0)
merryfrankster is online now
